Ohlins 911 Carrera / GT3 (996) DEDICATED Track Pre-Tuned Monotube Package
The Öhlins Dedicated Track Monotube Suspension Package for the Porsche 911 Carrera and GT3 (996) is a pre-tuned, bolt-on track suspension system built for drivers who demand circuit-ready performance straight from the box. Developed using Öhlins' Dual Flow Valve (DFV) technology and paired with Swift springs manufactured to Öhlins specifications, this package delivers precise, repeatable handling at the limit. The kit includes spherical upper mounts front and rear, eliminating the compliance found in factory rubber mounts for sharper turn-in response and consistent alignment geometry under sustained load.
The DFV system allows fluid to flow efficiently in both compression and rebound phases. At low shaft speeds, fluid passes through the bleed circuit for controlled damping. As shaft speed increases, flow transitions through the piston ports, and under high load or sudden impacts, the DFV opens to allow additional flow. This results in improved bump absorption, increased traction, and reduced harshness — critical for maintaining speed and consistency through extended track sessions.
Öhlins' temperature-reactive needle bleed valve compensates for changes in fluid viscosity as damper temperatures rise during sustained track use. This ensures predictable handling and repeatable lap times, even in the most demanding conditions.
Ride height is set to a target reduction of approximately 0–20mm from factory height. Additional height adjusters front and rear allow precise fine-tuning of rake and balance without altering spring preload or compromising suspension travel.
Product Details
- SKU: POU MU10S1
- Öhlins Dual Flow Valve (DFV) technology
- Single external adjuster with 25 clicks controlling compression and rebound
- Target ride height reduction: approximately 0–20mm
- Spring rates: 110 N/mm front, 150 N/mm rear (Swift, manufactured to Öhlins specifications)
- Spherical upper mounts included — front and rear
- Additional height adjusters — front and rear
- Monotube damper construction
- Rebuildable and serviceable dampers
- Pre-tuned for dedicated track use
Front Suspension Features
- McPherson strut design with inverted monotube construction
- Spherical bearing upper mounts
- Spring preload adjustment
- Height adjustable via lower perch and additional height adjuster
Rear Suspension Features
- Aluminum monotube shock absorber
- Spherical bearing upper mounts
- Spring preload adjustment
- Height adjustable via additional height adjuster
Vehicle Applications
- Porsche 911 Carrera (996)
- Porsche 911 GT3 (996)
Technical Resources
Notes
- Suspension components are non-returnable once installed
- Spherical upper mounts will transmit more noise, vibration, and harshness than factory rubber mounts — this is inherent to the design and expected for track-focused components
- The Porsche 911 (996) was not equipped with factory electronic dampers — no cancellation kit is required
