CANchecked TMC04 Tire Temperature Monitoring Set - Cabled

The CANchecked TMC04 Tire Temperature Monitoring Set provides professional-grade tire temperature monitoring through a complete four-sensor infrared measurement system with direct CAN bus communication. Designed for motorsport, track day, and advanced vehicle development applications, the TMC04 allows drivers, tuners, and engineers to monitor tire surface temperatures across all four corners of the vehicle in real time, delivering valuable data for suspension tuning, tire pressure optimization, alignment adjustments, and overall chassis setup.

Unlike wireless monitoring systems, the TMC04 utilizes a hardwired sensor architecture to provide consistent, uninterrupted communication in demanding motorsport environments. Each sensor supports up to 16 configurable measurement channels, allowing detailed temperature mapping across the tire contact patch for a deeper understanding of tire behavior and vehicle balance during on-track operation.

Operating across a temperature range of -40°C to +300°C with an accuracy of ±1°C, the TMC04 provides highly detailed thermal analysis suitable for everything from high-performance street vehicles to dedicated race cars. The adjustable refresh rate of up to 64 Hz ensures rapid data acquisition, while direct CAN bus integration allows seamless communication with CAN-enabled ECUs, displays, and data logging systems.

Built around compact IP66-rated aluminum housings, each sensor is engineered to withstand the harsh conditions commonly encountered in motorsport applications. Configurable CAN communication parameters, selectable CAN termination options, and support for both CAN 2.0A and CAN 2.0B protocols provide compatibility with a wide range of aftermarket electronics and motorsport platforms.

Product Details

• Complete four-corner tire temperature monitoring system
• Includes four infrared tire temperature sensors
• Up to 16 configurable measurement channels per sensor
• Temperature measurement range from -40°C to +300°C
• ±1°C measurement accuracy
• 110° standard field of view
• Optional 55° lens available upon request
• Adjustable refresh rates up to 64 Hz
• CAN 2.0A and CAN 2.0B compatibility
• Configurable CAN IDs and communication parameters
• Selectable CAN termination options
• IP66-rated aluminum sensor housings
• Operating voltage range from 5V to 20V
• Includes 0.5m AWG22 cable and DTM04-4P connector for each sensor

What's Included

• 4x TMC04 Infrared Tire Temperature Sensors
• 4x 0.5m AWG22 Sensor Cables
• 4x DTM04-4P Connectors
